A few days after its debut in China, Redmi Note 17 Pro is already under the knife. A teardown video has in fact shown in detail the internal structure of the smartphone, highlighting some of the solutions adopted by Xiaomi to maximize endurance, heat dissipation and durability.
The standout feature is undoubtedly the 9,000 mAh battery, but the device also hides several interesting technical choices.
Redmi Note 17 Pro: the teardown video shows the 9,000 mAh battery and all the secrets of the new Xiaomi
After removing the plastic rear cover, the teardown reveals a protective foam layer designed to improve water and dust resistance.
The most evident element is, however, the 9.000 mAh battery, produced by Sunwoda and characterized by a 13% silicon content. Clearly we are talking about a silicon-carbon solution, which allows increasing energy density while keeping compact dimensions.
With a high capacity, fast charging support could not be missing: the 67W charger included in the box completes a 0 to 100% in about 84 minutes, with a maximum detected power of 54.7W.
To manage heat, Xiaomi has integrated a 4,700 mm2 vapor chamber, located under the display. The internal frame uses instead an HZH5.9 alloy, which offers 30% higher rigidity than the previous generation.
Inside there is also the NFC coil, positioned next to the camera module, and a thermal film that promotes heat transfer between the battery and the motherboard.
Redmi Note 17 Pro uses RAM LPDDR4X together with storage UFS 4.0 produced by Samsung. However, due to the limitations of the Snapdragon 6s Gen 4 processor, the performance is equivalent to the UFS 3.1 standard.
The camera system includes a Samsung ISOCELL JN5 main sensor, while the front camera is based on the OmniVision OV08F sensor. Among other features are a USB 2.0 port, two microphones and an ultrasonic proximity sensor.
The teardown has also highlighted the display performance. According to tests, the panel reaches around 863 nits with manual brightness, climbs to 1.100 nits in high-brightness mode and can exceed 3.800 nits peak on limited portions of the screen.
Overall, the video confirms that Redmi Note 17 Pro was designed to prioritize endurance and solidity above all. At the moment the series has been unveiled in China and there is no official information on a global debut; however, in recent hours, a possible date (very near) but pertaining to the Indian market.
Technical specifications
- Dimensions and weight: 163.45 x 78.27 x 8.46 mm, 226 grams
- Colors: Sky Blue, Nebula Purple, White, Black
- Certification: IP66/IP68/IP69/IP69K
- Display: Flat AMOLED 6.85″ 1.5K (2,772 x 1,280 pixels) with 120 Hz refresh rate, touch sampling at 240 Hz (instant 3,200 Hz), 3,500 nit peak brightness (from 1 nit), PWM at 3,840 Hz and DC Dimming, 12-bit color, Gorilla Glass Victus 2 protection
- Security: under-display optical fingerprint sensor
- Cooling: liquid cooling with vapor chamber
- SoC: Qualcomm Snapdragon 6s Gen 4, 4 nm Samsung
- CPU octa-core
- 4 x 2.4 GHz – Cortex-A78
- 4 x 1.8 GHz – Cortex-A55
- GPU: Adreno 710
- RAM: 8/12 GB LPDDR4X
- Storage: 128 GB UFS 2.1, 256/512 GB UFS 3.1 not expandable
- Battery: 9.000 mAh
- Charging: 67W, reverse 22.5W
- Camera: dual 50 + 2 MP (f/1.8-2.4) with depth of field
- Selfie camera: 8 MP (f/2.0)
- Connectivity and others: Dual SIM 5G, Wi-Fi 5, Bluetooth 5.1, NFC, GPS, stereo speaker, USB-C, IR sensor
- Operating system: Android 16 with Xiaomi HyperOS 3
